Canon imageFORCE C1700 series color multifunction printer, three-quarter view

Showing: Angled view

CanonimageFORCE C1743F

Fast color print, copy, scan, and fax for the workgroup that outgrew its desktop printer.

Best for: Small and mid-size workgroups that need fast color print, copy, scan, and fax on a desktop or compact stand

  • Speed: 45 ppm
  • Output: Color
  • Max size: Legal
Already leasing a copier? Get a free cost comparison

Overview

About the imageFORCE C1743F

The imageFORCE C1743F is the 45-page-per-minute model in Canon's C1700 series — a color A4 multifunction printer for small and mid-size workgroups that need print, copy, scan, send, and fax in one compact device. Introduced in October 2026, it replaces the Color imageCLASS X MF1333C and brings the imageFORCE platform, security, and 7-inch touchscreen interface to the desktop class. The C1752F is the same system unlocked to 55 ppm by a speed license; the C1743P is the print-only version.

The 100-sheet single-pass duplex document feeder scans both sides of a page at up to 200 images per minute and sends searchable PDFs, PDF/A, or editable Word and PowerPoint files to email, folders, USB, mobile devices, or the cloud. Print from Windows, Mac, iOS, Android, and Chrome OS devices with AirPrint, Mopria, Universal Print, or the Canon PRINT app — no driver required. Paper capacity starts at 650 sheets (a 550-sheet cassette plus a 100-sheet multipurpose tray) and grows to 2,300 sheets with optional cassettes, handling stock to 80 lb cover and sizes up to 8-1/2 × 14.

Security matches the larger imageFORCE models: Verify System at Startup, Automatic System Recovery, Trellix™ Embedded Control, FIPS 140-3 TLS 1.3 and IPsec, two-factor authentication, and Microsoft Entra ID login are all standard. Fax is built in with a 30,000-page memory, and optional uniFLOW Online adds secure print release and cost tracking.

Key features

What it does well

  • 45 ppm with a fast first page

    Prints and copies at up to 45 pages per minute in color or black-and-white, with a first print in about 8 seconds and a 4-second quick startup. The same engine can be unlocked to 55 ppm with the C1752F speed license, so the device can grow with the office.

  • 100-sheet single-pass duplex scanning

    Both sides of a page in one pass at up to 200 images per minute to email, network folders (SMB, FTP, SFTP, WebDAV), USB, mobile devices, or uniFLOW Online as searchable PDF, PDF/A, or editable Word and PowerPoint files. Super G3 fax is standard.

  • Up to 2,300 sheets, Legal size

    A 550-sheet cassette and 100-sheet multipurpose tray standard; add Cassette Module-AL1 units or the Cassette Feeding Unit-BA1 to reach 2,300 sheets. Runs stock from 16 lb bond to 80 lb cover, plus envelopes, labels, and postcards up to 8-1/2 × 14.

  • Print from any device

    AirPrint, Mopria, IPP Everywhere, Canon PRINT, and Universal Print print without a driver install; UFR II, PCL 6, and PostScript 3 are standard. Gigabit Ethernet and wireless LAN are both built in, with dual-network operation supported.

  • Security designed into the device

    Verify System at Startup and Automatic System Recovery protect the firmware, Trellix™ Embedded Control whitelists what can run, and TLS 1.3 and IPsec are FIPS 140-3 validated. Secure Print and Forced Hold keep jobs at the device until the owner signs in by PIN, picture, card, password, or mobile; Microsoft Entra ID login is supported.

  • One interface across the whole lineup

    A 7-inch tiltable color touchscreen with the same icon-based layout as every other imageFORCE model, so anyone trained on one device can run another. Settings can be customized by an administrator to simplify daily tasks.

  • Low-impact by design

    ENERGY STAR® certified and rated EPEAT Bronze, with a 1.5 W sleep mode and a typical electricity consumption of 0.52 kWh per week. All-in-one Toner 1009 cartridges yield 18,700 black and 12,000 color impressions.

Buying guide

Is the imageFORCE C1743F right for your office?

Small and mid-size workgroups that have outgrown an entry-level desktop unit are the target for the imageFORCE C1743F. It prints and copies 45 ppm in color or black-and-white, scans both sides of a page at 200 ipm from a 100-sheet feeder, and includes Super G3 fax with memory for up to 30,000 pages. Paper starts at 650 sheets and expands to 2,300.

The detail that sets this color multifunction printer apart is room to grow: the C1752F is the same hardware unlocked to 55 ppm by a speed license. Its all-in-one T1009 cartridges are rated for 18,700 black and 12,000 color impressions. Introduced in October 2026, it replaces the Color imageCLASS X MF1333C.

How it compares

  • The C1752F is the same device licensed to run 55 ppm instead of 45. Scanner, fax, 7-inch screen, and 2,300-sheet capacity are identical to the C1743F.

    See the Canon imageFORCE C1752F
  • The C1743P prints at the same 45 ppm with the same paper capacity but has no scanner, copier, or fax, and stands 16-1/2 inches tall versus 25-3/8 for the C1743F.

    See the Canon imageFORCE C1743P
  • The C431F also runs 45 ppm with a 200 ipm scanner and fax, but adds a 10.1-inch screen, a 256 GB SSD, and a stapling twin in the C431FZ, an option the C1743F lacks.

    See the Canon imageFORCE C431F

Why buy from ABC

What you get from ABC

The imageFORCE C1743F is the same everywhere. What's different is the 44 years of local service behind it.

  • Delivery and network setup

    We deliver, unbox, place, and connect the device to your network and every workstation that needs it. You print the first page before we leave.

  • On-site staff training

    A Canon-certified technician walks your staff through the panel, scanning workflows, and the everyday things that generate service calls when nobody explains them.

  • Toner with your service plan

    With an active service plan, supplies ship before you run out, based on your device's own meter readings. Genuine Canon consumables only, so your warranty and image quality stay intact.

  • Same-day service standard

    Local technicians dispatched from our office in Old Hickory, not a national ticket queue. Average response is under four hours.

  • Plain-language agreements

    Lease, rent, or buy. Separate color and mono cost-per-page, and a person who answers questions about the contract by name.

  • Your own account manager

    The same person from proposal through the life of the system. They know your account, your volumes, and when it's time to talk about what's next.

“I called them and we had a multifunction printer the next afternoon. This solution will end up savings us hundreds a month in our environment.”
Dave Cook · Google reviewRead all our reviews on Google(opens in a new tab)

Get in Touch

Call, email, or send a message — whichever is easiest for you. We'll take it from there.

Specifications

The numbers

View full spec sheet
General
Technology / type
Laser, A4 color multifunction printer
Core functions
Print, copy, scan, send, fax (standard)
Control panel
7-inch TFT LCD WVGA color touchscreen, tiltable
Print
Print / copy speed
Up to 45 ppm (Letter), color and black-and-white
First print out time
Approx. 8.2 seconds
Print resolution
Up to 1200 × 1200 dpi (equivalent)
Page description languages
UFR II, PCL 6 / PCL 5, Adobe PostScript 3 (standard)
Mobile and cloud printing
AirPrint, Mopria, IPP Everywhere, Canon PRINT, Universal Print, and uniFLOW Online (optional)
Print security features
Secure Print, Encrypted Secure Print, Forced Hold Printing, uniFLOW Secure Print
Warm-up time
Quick Startup: 4 seconds or less; from Sleep: 10 seconds or less
Scan
Scan speed (Letter, 300 dpi send)
Single-sided: up to 100 ipm. Double-sided: up to 200 ipm (Automatic Color Select off)
Document feeder
Single-pass duplex automatic document feeder, 100-sheet capacity, originals to 8-1/2 × 14 (42–128 gsm)
Scan resolution
Up to 600 × 600 dpi
Scan destinations
Email, Internet fax, network folders (SMB, FTP, SFTP, FTPS, WebDAV), USB memory, mobile devices, cloud (uniFLOW Online); Super G3 fax
File formats
PDF (Compact, Searchable, PDF/A-1b, Trace & Smooth, Encrypted, Device/User Signature), XPS (Compact), TIFF, JPEG, Office Open XML (Word, PowerPoint)
Fax
Fax
Super G3 33.6 kbps; up to 30,000 pages / 2,000 jobs memory; 200 speed dials; 256-address broadcast
Paper handling
Paper capacity (Letter, 20 lb bond)
Standard 650 sheets (550-sheet cassette + 100-sheet multipurpose tray); maximum 2,300 sheets
Maximum paper size
8-1/2 × 14 (Legal) from the cassette and multipurpose tray
Media weights
Cassettes and duplexing: 16 lb bond to 74 lb cover (60–200 gsm). Multipurpose tray: 16 lb bond to 80 lb cover (60–216 gsm)
Media types
Thin, plain, recycled, color, heavy, bond, coated, labels, pre-punched, letterhead; multipurpose tray adds envelopes (COM10, Monarch, C5, DL) and postcards
Paper feeding options
Cassette Module-AL1 (550 sheets, up to two); Cassette Feeding Unit-BA1 (550 sheets); Cabinet Type-Z
Finishing options
Output capacity (Letter, 20 lb bond)
400 sheets; collate and group
Connectivity
Network
Gigabit Ethernet and wireless LAN standard (2.4 GHz; 5 GHz with license activation); dual network support
USB
Two USB 2.0 host ports, USB 2.0 device
Operating systems
Windows 10/11 and Server 2016–2025, macOS 11.7 or later, iOS, iPadOS, Android, Chrome OS
Software and management
Workflow and cloud
Optional uniFLOW Online for secure print release, cost tracking, and scan-to-cloud
Fleet management
imageWARE Enterprise Management Console: monitor status and supplies, apply security settings, update firmware, and capture meter readings remotely
Security
Authentication
Picture, PIN, card, username/password, mobile, and two-factor login; Department ID; Microsoft Entra ID; Access Management System; uniFLOW Online
Device security
Verify System at Startup and Automatic System Recovery (NIST SP 800-193); Trellix™ Embedded Control runtime intrusion detection; Standard Storage Initialize; optional TPM 2.0
Network and auditing
TLS 1.3 and IPsec (FIPS 140-3), IEEE 802.1X, SNMPv3, WPA3, IP/MAC filtering firewall, S/MIME, fax and USB separation from LAN
System
Processor
1.6 GHz dual-core plus 800 MHz single-core
Memory
2.5 GB RAM
Storage
64 GB eMMC (30 GB available)
Physical
Dimensions (W × D × H)
19-3/4 × 23-3/4 × 25-3/8 in (500 × 603 × 645 mm)
Weight
Approx. 97 lb (44 kg)
Environmental
Certifications
ENERGY STAR® certified; EPEAT Bronze
Power
110–127 V, 60 Hz, 15 A; sleep mode approx. 1.5 W; typical electricity consumption 0.52 kWh/week
Consumables
Toner
Toner T1009 BK/C/M/Y all-in-one cartridges — up to 18,700 impressions black, 12,000 impressions each color (ships with starter toner: 3,800 black, 3,100 each color)

Specifications are summarized from Canon's published materials and can change; confirm details on the Canon spec sheet or with our team before ordering.
